MD1017 Boxed Crown Moulding — 8¼″P x 13⅝″H x 12′L
- SKU:
- MD1017
- MPN:
- MD1017
- Condition:
- New
- Availability:
- Typically Ships within 2-3 weeks from Order Date and must be shipped to a COMMERCIAL BUSINESS ADDRESS.
- Width:
- 144.00 (in)
- Height:
- 13.60 (in)
- Depth:
- 8.25 (in)
- Shipping:
- Calculated at Checkout
Description
MD1017 Boxed Crown Moulding
MD1017 boxed crown moulding combines an upper curved crown with a deep horizontal return and a tall profiled lower fascia. Its stepped, boxed section creates a substantial architectural cornice with an 8¼-inch projection and 13⅝-inch overall height. Each 12-foot polyurethane length arrives factory-primed white and ready for finishing.
Plan your order & delivery
Made for your project
MD1017 is made to order and cannot be returned. Confirm the profile, dimensions and quantity before purchasing. A sample-cut option is available above.
Ships by freight
The 12-foot lengths travel in a crate by LTL truck freight. Full-length pieces cannot ship by standard parcel service.
Check the delivery address
Use a verified commercial address with access for a 52-foot trailer. A home business is considered residential. If the carrier classifies the address as residential, a $275 fee applies.
Allow time for production
The current estimate is typically 2–3 weeks from the order date. Contact us before ordering if your project has a specific deadline.
Check the fit
Projection is the maximum depth from the mounting surface. Height is the vertical dimension shown in the drawing.
The CAD drawing shows a 5⅝″ upper crown section and an 8″ lower fascia, totaling 13⅝″. The overall projection is 8¼″. Check the full boxed section, return depth and mounting arrangement against your wall and soffit before ordering.
Installation & finishing
- Fit the moulding to a clean, solid mounting surface. Do not install over wallpaper.
- Cut and fasten with standard woodworking tools. Use ADH100 adhesive on every bedding face and butt joint, with the recommended screws or finish nails.
- Finish the factory-primed surface according to Spectis instructions and paint promptly after installation. Fasteners and finish are sold separately.
MD1017 at a glance
- Profile
- Boxed crown with an upper curved face, horizontal return and tall lower fascia
- Material
- High-density polyurethane
- Finish
- Factory-primed white
- Use
- Interior and exterior trim with the standard material option
- Curved work
- This listing does not offer a flex material option. Contact Spectis before planning a curved application.
- Production
- Made to order
- Delivery
- Crated LTL freight for full-length pieces
Drawings & resources
Check the exact profile and dimensions in the drawing. Both PDFs open in a separate tab.
MD1017 FAQs
What is MD1017 made of?
High-density polyurethane (HDP). It can be cut and fastened with standard woodworking tools and resists rot and insect damage.
Can I use it indoors and outdoors?
Standard MD1017 is suitable for interior and exterior trim. This listing does not offer a flex material option. Contact Spectis before planning a curved application.
Does it need painting?
MD1017 arrives factory-primed and ready for finishing. No extra primer or sanding is normally needed before painting. Follow the Spectis finishing instructions and paint promptly after installation.
Which adhesive should I use?
Use ADH100 adhesive on every bedding face and butt joint, along with the recommended fasteners. Follow the crown moulding installation instructions.
How does a 12-foot length ship?
MD1017 ships by LTL freight in a crate. Use a verified commercial address that can accommodate a 52-foot trailer. A home office is still considered residential. Our shipping policy lists a $275 residential fee if the carrier classifies the address as a residence; delivery arrangements should be confirmed before ordering.
When will my order ship?
MD1017 is made to order. The estimated lead time is typically 2–3 weeks from the order date. Confirm timing with Spectis for your project.
Can I return it?
Made-to-order products cannot be returned. Check the dimensions and PDF drawing before purchasing. Use the sample-cut option on the product page if you want to review the profile first.
What if my order arrives damaged?
Inspect the shipment at delivery, report damage to the carrier immediately, and email sales@spectis.us the same day. Our shipping policy requires notification within 24 hours to qualify items for a claim.
Is there a warranty?
The Spectis warranty covers defects in materials and workmanship for five years for the original end user when the product is used and installed under recommended conditions. If it is not painted immediately after installation, the warranty period is one year. Read the full Spectis warranty for terms.
Need help checking the fit?
Have your measurements and part number MD1017 ready.
Builders, designers, and customers: if Spectis products or the installation steps are modified, you agree to indemnify, defend, and hold harmless Veritas Products LLC, veritasproducts.com, and spectis.us from any claimed loss or damage, regardless of other instructions.
